Castor Seeds Screw Oil Press

Castor Seeds Screw Oil Press Specification

Product Type
Cold & Hot Pressing Machine

Technology
Semi Automatic

Voltage
280,380,440 Volt (v)

Power Consumption
80 Horsepower (HP)

Dimension (L*W*H)
10.2 x 4.1 x 7.7

Weight
5200 kgs with Long Kettle, 6500 kgs with Three Stage Round Kettle

Warranty
1 year warranty against manufacturing defect.

Castor Seeds Screw Oil Press Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
300 Pieces Per Year

Delivery Time
50 Days

Packaging Details
"Wrapped in polythene sheet. For Exports additionally packed in export quality wooden box."

Certifications
ISO 9001:2008, ISO 14001 : 2015 Certified

About Castor Seeds Screw Oil Press

Castor Seeds Screw Oil Press is used to extract oil from various types of edible oil seeds as well as non-edible oil seeds & nuts.

This Oil Extraction Machine comes with both Horizontal & Vertical Kettle / Cooker.

Features:

Bodies and Base	Fabricated from Mild steel
Gearbox	Double Reduction Gearbox with Helical Gears of Cast Steel and Pinions of Alloy Steel
Chamber	Material: Cast Steel. Vertically fitted Feed End: - Size: 9" x 24" Long, Discharge End: - Size: 7" x 36" Long
Worm Assembly	Heat Treated in Feed Side Chamber and Hard Face welded in Discharge Side Chamber
Main Worm Shaft	Can be withdrawn out without Disturbing the Gear Box.
Round Kettle	3 or 4 stages with Steam Jackets of 48 Dia for efficient cooking of Seed. Pipe Fitting Contains Safety Valve, Steam Spray Pipe, Pressure Gauge, Steam Valves & Steam Traps. (Long Kettle provided as per requirement)
Cake Thickness	Can be Adjusted on Running Machine.
Crammer Shaft	For extra Cramming of the Seed or Cake in the Feed Body.
Oil & Oil Cake	Superior Quality
Maintenance	Minimum
Crushing capacity	Differs with the density of oilseeds & nuts and quantity of oil in it.

Optimized Extraction Technology

Equipped with semi-automatic controls, this screw oil press utilizes advanced mechanical pressing to achieve high oil yield from castor seeds. Its rugged design and customizable kettle options accommodate diverse processing needs, ensuring efficient operation in varied industrial settings.

Versatile Industrial Applications

The machine serves as a pivotal component for oil mills and agro-industries, capable of processing significant quantities with minimal power consumption. Its flexibility and reliability make it an ideal solution for oil manufacturers and exporters across India and global markets.

FAQs of Castor Seeds Screw Oil Press:

Q: How does the Castor Seeds Screw Oil Press operate?

A: The press utilizes a screw-driven mechanism, where castor seeds are fed into a semi-automatic system. Through continuous mechanical pressure, the seeds are efficiently crushed and oil is extracted, ensuring maximum yield with minimal labor.

Q: What are the major benefits of using this oil press?

A: This machine provides high oil extraction rates, reduced manual intervention thanks to semi-automatic technology, and flexibility with different kettle sizes. Its robust build and warranty offer reliability and long-term operation for commercial users.

Q: When should the screw oil press be maintained for optimal performance?

A: Regular maintenance intervals depend on usage frequency but are generally recommended after every intensive extraction cycle. Checking and servicing key components ensures continued efficiency and prolongs the equipments life.

Q: Where is this oil press typically installed?

A: The Castor Seeds Screw Oil Press is primarily installed in oil mills, industrial processing plants, and large-scale agro-industrial facilities. Its size and power requirements make it suitable for professional, high-volume setups.

Q: What is the process for extracting oil using this machine?

A: Castor seeds are loaded into the press, which then crushes and squeezes the seeds through its screw mechanism. The oil is collected for further refinement, while seed cake is automatically separated as a byproduct.

Q: How much power does the oil press consume during operation?

A: The press requires 80 horsepower during operation, making it energy-efficient for high-capacity processing, and is compatible with 280, 380, and 440 Volt power supplies.

Q: What warranty coverage accompanies this oil press?

A: The machine is covered by a 1-year warranty against manufacturing defects, providing assurance on build quality and manufacturer support for buyers.
