Cottonseed Oil Press Machine

Cottonseed Oil Press Machine Specification

Type
Oil Press Machine

Material
Mild Steel

Computerized
No

Voltage
220V , 280V ,380V , 400V , 415V Volt (v)

Warranty
1 year warranty against Manufacturing Defect

Cottonseed Oil Press Machine Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Telegraphic Transfer (T/T), Letter of Credit (L/C)

Supply Ability
50 Pieces Per Year

Delivery Time
30 Days

Packaging Details
"Wrapped in polythene sheet. For Exports additionally packed in export quality wooden box."

Main Export Market(s)
Australia, Central America, North America, Asia, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
All India

Certifications
ISO 9001:2008, ISO 14001 : 2015 Certified

About Cottonseed Oil Press Machine

Cottonseed Oil Press Machine is used to extract oil from various types of edible as well as non-edible oil seeds & nuts.

Features:

Bodies and Base	Fabricated from Mild steel
Gearbox	Triple Reduction Gearbox with Helical Gears of Cast Steel and Pinions of Alloy Steel. Aligned with bodies on single fabricated base.
Chamber	Material: Cast Steel. Vertically fitted Feed End: - Size: 12" x 36" Long, Middle: Size: 11" x 36" Long, Discharge End: - Size: 10" x 36" Long
Worm Assembly	Hard Face welded along with Discharge Ring and Sliding Ring
Main Worm Shaft	Can be withdrawn out without Disturbing the Gear Box. The Shaft is water cooled.
Crammer Shaft	For Extra Cramming of the Seed or Cake is fitted on the Feed Body and is driven by 3 H.P. Geared Motor.
Round Kettle (Cooker)	5 Stages with Steam Jackets of 66 Dia for efficient cooking of Seed. Pipe Fitting Contains Safety Valve, Steam Spray Pipe, Pressure Gauge, Steam Valves & Steam Traps. Exhaust Fan is also provided to extract excess steam or moisture from cooking chambers. Supported separately on fabricated structure
Cake Thickness	Can be Adjusted on Running Machine.
Oil & Oil Cake	Superior Quality
Maintenance	Minimum
Chamber Lifting	Manual
Crushing Capacity	Differs with the density of oilseeds & nuts and quantity of oil in it.)

High-Capacity Oil Extraction

This oil press machine is engineered for rigorous, high-volume processing. Whether you aim for pre-pressing or final crushing, the equipment supports substantial capacity. It achieves 110-125 tons per day for pre-pressing and 45-55 tons daily in single or final pressing, significantly increasing productivity and reducing manual intervention.

Robust Build and Flexible Operation

Constructed with sturdy mild steel, the machine ensures longevity and reliability in industrial environments. Its semi-automatic operation suits a range of voltage requirements, making it adaptable for facilities worldwide. The integrated design includes the expeller, cooker, and supporting structure, all contributing to seamless workflow.

After-Sales Assurance and Support

Investing in this oil press machine comes with the assurance of a one-year warranty against manufacturing defects. This commitment underscores the manufacturer's confidence in product quality and ensures peace of mind for operators and business owners during daily use.

FAQ's of Cottonseed Oil Press Machine:

Q: How does the cottonseed oil press machine operate?

A: This semi-automatic machine uses mechanical pressing to extract oil from cottonseed. The process is divided into pre-pressing (initial extraction) and final crushing (residual extraction), ensuring maximum yield from each seed batch.

Q: What materials are used in the construction of this machine?

A: The entire unit is manufactured using high-quality mild steel, including the expeller, cooker, and supporting structure, providing excellent durability for long-term industrial use.

Q: What are the production capacities for pre-pressing and final crushing?

A: During pre-pressing, the machine can process 110-125 tons of cottonseed in 24 hours. For single and final crushing, it achieves a capacity of 45-55 tons over the same period.

Q: When can I expect after-sales support and warranty coverage?

A: A one-year warranty is provided against manufacturing defects from the date of purchase, ensuring support for any issues during the initial period of operation.

Q: Where is this machine manufactured and can it be exported?

A: This oil press machine is manufactured in India and is available for export to international markets, making it suitable for exporters, suppliers, and manufacturers worldwide.

Q: What are the voltage and power requirements for operation?

A: The unit operates efficiently across a range of voltages-220V, 280V, 380V, 400V, and 415V-and requires a power input of 175 horsepower (HP).

Q: What are the key benefits of using this oil press machine?

A: The main advantages include high oil yield, robust steel construction for extended life, flexible voltage compatibility, substantial daily processing capacity, and reliable after-sales support with a one-year warranty.
