Features:
|
Bodies and Base |
Fabricated from Mild steel |
|
Gearbox |
Double Reduction Gearbox with Helical Gears of Cast Steel and Pinions of Alloy Steel. |
|
Chamber |
Steel Casting of Four Sections. Horizontally fitted Size: 7.5 dia X 6.5 dia X 45 dia Long. |
|
Worm Assembly |
Hard Faced along with Discharge Ring and Compression Ring |
|
Main Worm Shaft |
Can be withdrawn out without Disturbing the Gear Box. |
|
Kettle |
3 or 4 stages with Steam Jackets of 48 dia for efficient cooking of Seed. Pipe Fitting Contains Safety Valve, Steam Spray Pipe, Pressure Gauge, Steam Valves & Steam Traps. |
|
Cake Thickness |
Can be Adjusted on Running Machine. |
|
Crammer Shaft |
For extra Cramming of the Seed or Cake in the Feed Body. |
|
Oil & Oil Cake |
Superior Quality |
|
Maintenance |
Minimum |
|
Crushing Capacity |
Differs with the density of oilseeds & nuts and quantity of oil in it. |



Price:
Price 2324000.0 INR / Piece
Minimum Order Quantity : 1 Piece
Dimension (L*W*H) : 10.7 x 4.7 x 4.7 Foot (ft)
Production Capacity : 20 22 Ton in 24 Hours( 1st Pressing )15 16 Ton in 24 Hours(2nd Pressing )
Warranty : 1 year against manufacturing defects
Weight (kg) : 5850 Kilograms (kg)
Price 1743000.0 INR / Unit
Minimum Order Quantity : 1 Unit
Dimension (L*W*H) : 8.8 x 4.6 x 9 Foot (ft)
Production Capacity : 12 15 Ton/day
Warranty : 1 year against manufacturing defects
Weight (kg) : 4500 Kilograms (kg)
Price 2635000 INR / Piece
Minimum Order Quantity : 1 Piece
Dimension (L*W*H) : 8.6 x 4.7 x 13 Foot (ft)
Production Capacity : 1517 Ton/day
Warranty : 1 year against manufacturing defects
Weight (kg) : 4800 kgs (With Three Stage Kettle), 5500 Kgs (With Four Stage Kettle)
Price 415000.0 INR / Piece
Minimum Order Quantity : 1 Piece
Dimension (L*W*H) : 7.2 x 2.3 x 4.8 Foot (ft)
Production Capacity : 23 Ton/day
Warranty : 1 year against manufacturing defects
Weight (kg) : 950 Kilograms (kg)
